Automatic Loader Machine
Working height: 900±20 (std)
Board time on board: 6.0 sec
Step selection: 10. 20. 30. 40MM select-able
Automatic Magazine Loader
Place of Origin: | CHINA |
Brand Name: | HE CAN |
Model Number: | loader |
Certification: | CE |
Feature
1. Special aluminum alloy mechanism, better understand the operation status of MAGAZINE.
2. The structure design of the stable casting lifting table improves the stability of the equipment.
3. Panasonic PLC control, mufti-function electrical circuit and programming, Stable performance to ensure smooth and smooth production line.
4. Humanized programming, 4 kinds of PITCH options, The step of receiving/sending PCB can be set.
5. Standard SMEMA communication interface, which can communicate with other automation equipment.
6. Adjustable push plate speed control.
7. Three-point positioning type up and down pneumatic clamping to ensure the accurate position of the material box.
8. Push board protection system to ensure that the PCB board will not be damaged, reducing process losses.
PCB size: | 50*50~330*250MM |
Working height: | 900±20 (std) |
Board time on board: | 6.0 sec |
Step selection: | 10. 20. 30. 40MM select-able |
Power supply and power: | AC 110/220V±10V, 50/60HZ |
Dimension: | 1330(L)*765(W)*1250(H) |
Weight: | 190KG |
Compressed air supply pressure: | ４－６bar |
Compressed air flow: | 10 L/min |
PCB thickness: | Min 0.6MM |
Delivery direction: | Left to right or customer specified |
